WV12-BM High Speed Computerized Chain Stitch Multi-Needle Quilting Machine

Automatic lubrication system enables labor saving and long life of the machine. Japanese famous brand bearings and precise casting spare parts are used on the machine, which ensures long life of the machine. Automatic stop when up or bottom thread is broken, and both up and down safety infrared protection.
Inquiry

  • ◆ Automatic lubrication system enables labor saving and long life of the machine.

    ◆ Japanese famous brand bearings and precise casting spare parts are used on the machine, which ensures long life of the machine.

    ◆ Automatic stop when up or bottom thread is broken, and both up and down safety infrared protection.

    ◆ Delta VFD (variable-frequency driver) drives main shaft (Z shaft), Panasonic servo driver & motor control the saddle (X shaft) and roller (Y shaft).

    ◆ Both serial patterns and Tack & Jump patterns (360° and 180°) are available.

    ◆ Controlling system based on Windows, CAD drawing.

    ◆ Automatic stop when pre-set processing length is finished, which is saving labor and easy operation.

    ◆ Automatic detection of machine running condition.


    1578307427475861.jpg 1578307428421376.jpg 1578307428404826.jpg 1578307428868266.jpg 1578307429420724.jpg

  • Dimension (L×W×H)5400×1650×2050 mm
    Weight4800KG
    Quilting width2450mm
    Needle bar distance50.8, 76.2, 127(5") / 76.2, 76.2, 152.4(6")
    Needle distance0.5 inch/ 1 inch
    X-axis movement displacement304.8 mm
    Quilting thickness≤80 mm
    Stitch length3-7 mm
    Capacity60-300 (m/hour)
    Needle type24/180   23/160   22/140  21/130
    Main shaft speed500-1200 (rpm)
    Voltage380V/50Hz, 220V/60Hz, 3-Phase
    Power7KW
